| USE [YHWCS]
GO
/****** Object: StoredProcedure [dbo].[P_时间统计报表] Script Date: 2024/7/23 11:09:33 ******/
SET ANSI_NULLS ON
GO
SET QUOTED_IDENTIFIER ON
GO
-- =============================================
-- Author:xiaoxianghui
-- Create date: 2024年7月5日
-- Description: 时间统计数据
-- =============================================
ALTER PROCEDURE [dbo].[P_时间统计报表]
@TaskNo nvarchar(50) = NULL,
@PalletId nvarchar(50) = NULL,
@PositionId nvarchar(50) = NULL,
@Tunner nvarchar(50) = NULL,
@PLCType nvarchar(50) = NULL,
@IoDate datetime = NULL
AS
BEGIN
SELECT
--distinct tps.Cn, tps.Id,
tps.CreateTime as "创建时间",
tps.Name as "设备名称",
case tps.PLCType
when 1 then '入库'
when 2 then '出库'
when 4 then '移库'
end as "指令类型",
tps.TaskNo as "工作编号",
tps.BarCode as "托盘编号",
tps.StartTime as "开始时间",
tps.EndTime as "结束时间",
--DATEDIFF(SECOND, tps.StartTime, tps.EndTime) AS "工作时间(秒)",
CASE
WHEN tps.PLCType = 1 AND tps.Name = '一层输送线' THEN NewTimeSubQuery1.NewTime
WHEN tps.PLCType = 2 AND tps.Name = '一层输送线' THEN NewTimeSubQuery2.NewTime
WHEN tps.PLCType in (1, 2) AND tps.Name = '双工位RGV' THEN NewTimeSubQuery3.NewTime
WHEN tps.PLCType in (1, 2) AND tps.Name like '%堆垛机' THEN NewTimeSubQuery4.NewTime
--WHEN tps.PLCType = 2 AND tps.Name = '双工位RGV' THEN NewTimeSubQuery5.NewTime
--WHEN tps.PLCType = 2 AND tps.Name like '%堆垛机' THEN NewTimeSubQuery6.NewTime
WHEN tps.PLCType = 1 AND tps.Name not in ( '一层输送线','双工位RGV', '%堆垛机') THEN NewTimeSubQuery7.NewTime
WHEN tps.PLCType = 2 AND tps.Name not in ( '一层输送线','双工位RGV', '%堆垛机') THEN NewTimeSubQuery8.NewTime
WHEN tps.PLCType = 4 AND tps.Name like '%堆垛机' THEN NewTimeSubQuery9.NewTime
ELSE NULL
END AS "流程时间(秒)",
--tps.StartDesign ,
--tps.EndDesign ,
--toh.ordIdNew as "工作编号",
--toh.palletId as "托盘编号",
--toh.srcPositionId as "移出仓位",
--toh.positionId as "仓位编号",
case toh.optType
when 0 then 'WMS错误' when 1 then '整入' when 2 then '补入' when 3 then '整出' when 4 then '分拣' when 5 then '空入' when 6 then '空出/补出' when 7 then '空盘移库' when 8 then '盘库' when 9 then '盘库返库' when 10 then '实盘移库' when 11 then '转移出库' when 12 then '转移入库' when 13 then '移动穿梭车'
end as "工控类型",
toh.ioDate as "工控日期",
--toh.optStation as "操作台",
--toh.pHs as "分配台位",
case toh.design
when -2 then '被删除的指令' when -1 then '待执行' when 0 then '堆垛机待命' when 1 then '堆垛机工作' when 2 then '未过账' when 3 then '已过帐' when 5 then '分拣到达' when 6 then '分拣返回' when 7 then '执行入库' when 8 then '重入未过账' when 9 then '重入已过账' when 10 then 'RGV待命' when 11 then 'RGV工作' when 12 then '线体等待'
end as "工控进程",
--toh.userId as "操作员",
case toh.sysType
when 0 then 'wms' when 1 then 'RF' when 2 then 'DPS' when 3 then '其他'
end as "系统下发",
case toh.byHand
when 0 then '自动' when 1 then '手动'
end as "指令方式",
--case toh.mStatus
-- when 0 then '已组盘' when 1 then '待执行' when 2 then '正在执行'
-- end as "生成状态",
case toh.dStatus
when 0 then '正常' when 1 then '暂停'
end as "执行状态",
--case toh.pltReturn
-- when 0 then '线体上' when 1 then '线体下'
-- end as "运动状态",
--case toh.PlcType
-- when 1 then '入库' when 2 then '出库' when 4 then '移库'
-- end as "指令类型",
toh.tunner as "巷道",
toh.mBillIds as "订单主编号集合"
FROM
tPLCServerLog tps
LEFT JOIN
tOrderHy toh ON tps.TaskNo = toh.ordIdNew AND tps.BarCode = toh.palletId
OUTER APPLY
(
SELECT
COALESCE(
DATEDIFF(SECOND,
MIN(CASE WHEN tps2.Name = '一层输送线' THEN tps2.StartTime ELSE NULL END),
MAX(CASE WHEN tps2.Name = '双工位RGV' THEN tps2.StartTime ELSE NULL END)),
DATEDIFF(SECOND,
MIN(CASE WHEN tps2.Name = '一层输送线' THEN tps2.StartTime END),
MAX(CASE WHEN tps2.Name = '一层输送线' THEN tps2.EndTime END))
) AS NewTime
FROM
tPLCServerLog tps2
--left join tOrderHy toh2 ON tps2.TaskNo = toh2.ordIdNew AND tps2.BarCode = toh2.palletId
WHERE
tps2.TaskNo = tps.TaskNo AND
tps2.BarCode = tps.BarCode AND
tps2.PLCType = 1
--DATEDIFF(SECOND, tps2.StartTime, tps2.EndTime) < 86400 and
--tps2.StartTime < tps2.EndTime and
--tps2.EndTime < toh2.ioDate and
--toh2.ordIdNew is not NULL and toh2.palletId is not NULL
) NewTimeSubQuery1
OUTER APPLY
(
SELECT
COALESCE(
DATEDIFF(SECOND,
MIN(CASE WHEN tps3.Name = '双工位RGV' THEN tps3.EndTime ELSE NULL END),
MAX(CASE WHEN tps3.Name = '一层输送线' THEN tps3.EndTime ELSE NULL END)
),
DATEDIFF(SECOND,
MAX(CASE WHEN tps3.Name = '一层输送线' THEN tps3.StartTime ELSE NULL END),
MAX(CASE WHEN tps3.Name = '一层输送线' THEN tps3.EndTime ELSE NULL END)
)) AS NewTime
FROM
tPLCServerLog tps3
--left join tOrderHy toh3 ON tps3.TaskNo = toh3.ordIdNew AND tps3.BarCode = toh3.palletId
WHERE
tps3.TaskNo = tps.TaskNo AND
tps3.BarCode = tps.BarCode AND
tps3.PLCType = 2
--DATEDIFF(SECOND, tps3.StartTime, tps3.EndTime) < 86400 and
--tps3.StartTime < tps3.EndTime and
----tps3.EndTime < toh3.ioDate and
--toh3.ordIdNew is not NULL and toh3.palletId is not NULL
) NewTimeSubQuery2
OUTER APPLY
(
SELECT
MIN(DATEDIFF(SECOND,
(CASE WHEN tps4.Name = '双工位RGV' THEN tps4.StartTime ELSE NULL END),
(CASE WHEN tps4.Name = '双工位RGV' THEN tps4.EndTime ELSE NULL END)
)) AS NewTime
FROM
tPLCServerLog tps4
--left join tOrderHy toh4 ON tps4.TaskNo = toh4.ordIdNew AND tps4.BarCode = toh4.palletId
WHERE
tps4.TaskNo = tps.TaskNo AND
tps4.BarCode = tps.BarCode AND
tps4.PLCType in (1, 2)
--DATEDIFF(SECOND, tps4.StartTime, tps4.EndTime) < 86400 and
--tps4.StartTime < tps4.EndTime and
--tps4.EndTime < toh4.ioDate and
--toh4.ordIdNew is not NULL and toh4.palletId is not NULL
) NewTimeSubQuery3
OUTER APPLY
(
SELECT
COALESCE(
DATEDIFF(SECOND,
MAX(CASE WHEN tps5.Name like '%堆垛机' THEN tps5.StartTime ELSE NULL END),
MAX(CASE WHEN tps5.Name like '%堆垛机' THEN tps5.EndTime ELSE NULL END)),
DATEDIFF(SECOND,
MAX(CASE WHEN tps5.Name like '%堆垛机' THEN tps5.StartTime ELSE NULL END),
MAX(CASE WHEN tps5.Name like '%堆垛机' THEN toh5.ioDate ELSE NULL END))
) AS NewTime
FROM
tPLCServerLog tps5
left join tOrderHy toh5 ON tps5.TaskNo = toh5.ordIdNew AND tps5.BarCode = toh5.palletId
WHERE
tps5.TaskNo = tps.TaskNo AND
tps5.BarCode = tps.BarCode AND
tps5.PLCType in (1, 2)
--DATEDIFF(SECOND, tps5.StartTime, tps5.EndTime) < 86400 and
--tps5.StartTime < tps5.EndTime and
--toh5.ordIdNew is not NULL and toh5.palletId is not NULL
----tps5.EndTime < toh5.ioDate
) NewTimeSubQuery4
--OUTER APPLY
--(
-- SELECT
-- MIN(DATEDIFF(SECOND,
-- (CASE WHEN tps6.Name = '双工位RGV' THEN tps6.StartTime ELSE NULL END),
-- (CASE WHEN tps6.Name = '双工位RGV' THEN tps6.EndTime ELSE NULL END)
-- )) AS NewTime
-- FROM
-- tPLCServerLog tps6
-- --left join tOrderHy toh6 ON tps6.TaskNo = toh6.ordIdNew AND tps6.BarCode = toh6.palletId
-- WHERE
-- tps6.TaskNo = tps.TaskNo AND
-- tps6.BarCode = tps.BarCode AND
-- tps6.PLCType = 2
-- --DATEDIFF(SECOND, tps6.StartTime, tps6.EndTime) < 86400 and
-- --tps6.StartTime < tps6.EndTime and
-- --tps6.EndTime < toh6.ioDate and
-- --toh6.ordIdNew is not NULL and toh6.palletId is not NULL
--) NewTimeSubQuery5
--OUTER APPLY
--(
-- SELECT
-- DATEDIFF(SECOND,
-- MAX(CASE WHEN tps7.Name like '%堆垛机' THEN tps7.StartTime ELSE NULL END),
-- MAX(CASE WHEN tps7.Name like '%堆垛机' THEN tps7.EndTime ELSE NULL END)
-- ) AS NewTime
-- FROM
-- tPLCServerLog tps7
-- --left join tOrderHy toh7 ON tps7.TaskNo = toh7.ordIdNew AND tps7.BarCode = toh7.palletId
-- WHERE
-- tps7.TaskNo = tps.TaskNo AND
-- tps7.BarCode = tps.BarCode AND
-- tps7.PLCType = 2
-- --DATEDIFF(SECOND, tps7.StartTime, tps7.EndTime) < 86400 and
-- --tps7.StartTime < tps7.EndTime and
-- --tps7.EndTime < toh7.ioDate and
-- --toh7.ordIdNew is not NULL and toh7.palletId is not NULL
--) NewTimeSubQuery6
OUTER APPLY
(
SELECT
DATEDIFF(SECOND,
MAX(CASE WHEN tps8.Name not in ( '一层输送线','双工位RGV', '%堆垛机') THEN tps8.StartTime ELSE NULL END),
MAX(CASE WHEN tps8.Name not in ( '一层输送线','双工位RGV', '%堆垛机') THEN tps8.EndTime ELSE NULL END)
) AS NewTime
FROM
tPLCServerLog tps8
--left join tOrderHy toh8 ON tps8.TaskNo = toh8.ordIdNew AND tps8.BarCode = toh8.palletId
WHERE
tps8.TaskNo = tps.TaskNo AND
tps8.BarCode = tps.BarCode AND
tps8.PLCType = 1
--DATEDIFF(SECOND, tps8.StartTime, tps8.EndTime) < 86400 and
--tps8.StartTime < tps8.EndTime and
--tps8.EndTime < toh8.ioDate and
--toh8.ordIdNew is not NULL and toh8.palletId is not NULL
) NewTimeSubQuery7
OUTER APPLY
(
SELECT
DATEDIFF(SECOND,
MAX(CASE WHEN tps9.Name not in ( '一层输送线','双工位RGV', '%堆垛机') THEN tps9.StartTime ELSE NULL END),
MAX(CASE WHEN tps9.Name not in ( '一层输送线','双工位RGV', '%堆垛机') THEN tps9.EndTime ELSE NULL END)
) AS NewTime
FROM
tPLCServerLog tps9
--left join tOrderHy toh9 ON tps9.TaskNo = toh9.ordIdNew AND tps9.BarCode = toh9.palletId
WHERE
tps9.TaskNo = tps.TaskNo AND
tps9.BarCode = tps.BarCode AND
tps9.PLCType = 2
--DATEDIFF(SECOND, tps9.StartTime, tps9.EndTime) < 86400 and
--tps9.StartTime < tps9.EndTime and
--tps9.EndTime < toh9.ioDate and
--toh9.ordIdNew is not NULL and toh9.palletId is not NULL
) NewTimeSubQuery8
OUTER APPLY
(
SELECT
DATEDIFF(SECOND,
MAX(CASE WHEN tps10.Name like '%堆垛机' THEN tps10.StartTime ELSE NULL END),
MAX(CASE WHEN tps10.Name like '%堆垛机' THEN tps10.EndTime ELSE NULL END)
) AS NewTime
FROM
tPLCServerLog tps10
--left join tOrderHy toh10 ON tps10.TaskNo = toh10.ordIdNew AND tps10.BarCode = toh10.palletId
WHERE
tps10.TaskNo = tps.TaskNo AND
tps10.BarCode = tps.BarCode AND
tps10.PLCType = 4
--DATEDIFF(SECOND, tps10.StartTime, tps10.EndTime) < 86400 and
--tps10.StartTime < tps10.EndTime and
--toh10.ordIdNew is not NULL and toh10.palletId is not NULL
--tps10.EndTime < toh10.ioDate
) NewTimeSubQuery9
where
-- --DATEDIFF(SECOND, tps.StartTime, tps.EndTime) < 86400 and
-- tps.Cn <> 0 AND
-- tps.StartTime IS NOT NULL AND
-- tps.EndTime IS NOT NULL AND
-- --tps.StartTime < tps.EndTime AND
-- toh.ordIdNew is not NULL and toh.palletId is not NULL
-- --DATEDIFF(SECOND, tps.StartTime, tps.EndTime) > 5
-- --AND tps.TaskNo = '17731' and tps.BarCode = 'T03452'
(@Tunner IS NULL OR @Tunner = '' OR toh.tunner = @Tunner)
AND (@TaskNo IS NULL OR @TaskNo = '' OR tps.TaskNo = @TaskNo)
AND (@PalletId IS NULL OR @PalletId = '' OR toh.palletId = @PalletId)
AND (@PositionId IS NULL OR @PositionId = '' OR toh.positionId = @PositionId OR srcpositionid=@PositionId)
AND (@PLCType IS NULL OR @PLCType = '' OR tps.PLCType = @PLCType)
AND (@IoDate IS NULL OR @IoDate = '' OR convert(varchar(10),toh.ioDate,21) = convert(varchar(10),@IoDate,21))
--order by tps.TaskNo, tps.BarCode
END
|
